TECHNICAL FEATURES

Engine:

CAT C4.4 ACERT STAGE III
CAT C3.6 STAGE V

Engine power:

106 Kw Stage III
100 Kw Stage V

Cabin:

ROPS - FOPS

Weight :

7.000Kg

Measurements:

6085mm x 1900mm x2300mm

Internal steering radius:

3000mm

External steering radius:

5350mm

Slope:

30%

Cabin climate control:

Yes

Brakes:

Service (oil bath) 4-wheel Multidisc
Parking 4-wheel negative

Platform:

2.400mm x 1.750mm

Max. platform height:

2700mm, 3680mm from ground

Speed:

20 Km/h

Pantograph lifting platforms manufactured by Maquinaria Lorenzana reach the most demanding levels of productivity thanks to the unique design of their platforms, the easy accessibility to controls, both at the platform and at the vehicle, their mobility and the 180º rotation of the platform. And all in all, we don’t forget the most strict safety measures, that added to the rest of the features, make SL-33 the definitive choice of the most demanding customers.
